VEHICLE SYSTEMS LAB

Understanding diverse car systems is essential for establishing knowledge and developing imagination and vision in order to analyse, create, and optimise automobiles for the future. The vehicle systems laboratory, which has the same objective, is well-equipped with all of the mechanical components of an automobile (two and four wheelers).

 Faculty in charge:  Mr. Nixon Poulose

Room No: DC103, DC128, DC126, DC121

List of equipment

1. Mahindra 2wd Gearbox
2. Ambassador Gearbox
3. Steering Gear Box
4. Maruti Cylinder Head
5. Calliper Assy (2 Nos)
6. Master Cylinder (2 Nos)
7. Force Engine Block
8. Ambassador Cylinder Head
9. AC Mechanical Fuel Pump
10. Inline Fuel Injection Pump
11. Clutch Assembly (2 Nos)
12. Clutch Puller
13. Diaphragm Clutch (2 Nos)
14. Brake Booster (2 Nos)
15. Rear Axle Unit (1Nos)
16. Propellor Shaft
17. Differential Unit (2 Nos)
18. Rack and Pinion
19. Worm and Roller
20. Growler
21. Battery Charger
22. Cylinder Boring Machine
23. Connecting Rod and Reboring Machine
24. Brake Drum and Disc Lathe
25. Valve Refacing Machine
26. Ignition System and Test Bench
27. Wheel Balancing Machine
28. Wheel Alignment Machine
29. Diesel Smoke Meter
30. Air Compressor with Tyre Inflator
31. Stop Watch Nivea
32. Drilling Machine
33. Grinding Machine
34. King Tony Socket Set (2 Nos)
35. Taparia Double End Spanner Set (2 Nos)
36. Taparia Ring Spanner Set (2 Nos)
37. Plier (7 Nos)
38. Hammer (4 Nos)
39. Screw Driver (7 Nos)
40. Grease Gun
41. Valve Lifter
42. Piston Ring Extractor
43. Bearing Puller (5 Nos)
44. Timing Light
45. Compression Guage for Petrol Engine
46. Dial Guage with Magnetic Stand
47. Cylinder Bore Guage
48. Telescopic Guage
49. Hydraulic Jack
50. Jack Stand
51. File Set
52. Hydrometer
53. Multimeter

AUTOTRONICS AND VEHICLE TESTING LAB

The Autotronics laboratory allows for the theoretical and practical examination of challenges in the realm of electrical and electronic technology as it applies to automobiles. A set of modules for studying basic electricity and main electric circuits, a set of simulation panels for electric and electronic systems in modern automobiles, complete with dedicated software for demonstrating relevant theory and introducing simulated faults, a set of panels with real components for demonstration, and a set of sectioned components.

Faculty in charge : Ms. Aggi Joseph

Room No : DC 208

List of equipment

1. Function Generator (2 Nos)
2. CRO - 20Mhz (2 Nos)
3. Displacement Sensor Panel (2 Nos)
4. Eight Bit Microprocessor 8085 (8 Nos)
5. Eight Bit Microprocessor 8086(2 Nos)
6. IC Regulated Power Supply (2 Nos)
7. Bread Board (12 Nos)
8. Power Supply (4 Nos)
9. Digital Multi Meter (4 Nos)
10. Analog Multi Meter (2 Nos)
11. Stepper Motor -2 Kg (2 Nos)
12. 2 Channel DAC Interface Board (4 Nos)
13. 8 Channel ADC Interface Board (4 Nos)
14. Wire Stripper (4 Nos)
15. Instrument Cluster Experiment Box with Path Trips
16. Power Window Experiment Box with Path Strips
17. Airflow Sensor Experiment Box
18. Crank Shaft Position Sensor Experiment Box
19. Hall Effect Sensor Experiment Box
20. Vehicle Speed Sensor Experiment Box
21. RTD (4 Nos)
22. Thermocouple (4 Nos)
23. Load Cell (4 Nos)
24. Stepper Motor Controller with Motor (8 Nos)
25. Screw Driver Set
26. Rectifier Trainer Module (4 Nos)
27. Transformer (4 Nos)

THERMAL ENGINEERING LAB

The thermal laboratory gives students a variety of opportunities to learn about different types of IC engines, analyse boiler performance, and work on new projects. Performance, heat balance, retardation, and emission tests can be performed on a range of IC engines, including single/double/multi cylinder engines with current mechanical/electrical/hydraulic loading devices.

Faculty in charge : Mr. Jinson Paul

Room No : DC 104, DC 102, DC 103

List of equipment

1. Flash Point -Pensky Martens Apparatus
2. Redwood Viscometer
3. Saybolt Viscometer electrically heated with energy regulator
4. Thermometer
5. Bomb Calorimeter
6. Industrial Oxygen Cylinder
7. Two Stage Regulator
8. Weighing Balance of accuracy 0.1 mg
9. Nickel Crucible
10. Quartz Crucible
11. Fuel Injection Pump Calibration Machine
12. 4-Cylinder 4 Stroke Diesel Engine test rig with Eddy current dynamometer
13. 4-Cylinder 4 Stroke MPFI Petrol Engine test rig with Hydraulic dynamometer
14. Twin Cylinder 4 Stroke Diesel Engine testing with Mechanical loading

PRODUCTION ENGINEERING LAB (Part-B)

Industry is in great need of professionals with thorough CNC (Computer Numerical Control) programming knowledge in India and abroad. It is a state-of-the-art training centre, offers high end training in CNC programming and CNC machining. The students acquired knowledge and experience in CNC programming, understand basic machining processes, learn to set up and adjust the tools and fixtures. Manufacturing trend has made a quantum leap towards CNC from conventional methods. This lab can also be used to manufacture certain components from the local companies. Faculty can use the equipment to manufacture components needed in their research project.

Faculty in charge: Dr. Ajithkumar J P Room No: DC117, DC118

List of equipment

1. CNC Milling Machine
2. CNC Lathe Machine
3. Air Compressor and Air Drier
4. Face Mill Cutters
5. End Mill Cutters
6. Side Lock Holders
7. Clamping Vices
8. Stabilizers
9. Collet Chucks
10. Collet ranges
11. Drill Bits
12. Dial Test Indicators
13. Vernier Callipers
14. Magnetic Stands
15. Tool Clamp Devices
